HIKVISION DS-7104HGHI-SH User Manual

User Manual of Digital Video Recorder
108
Figure 7. 9 Checkup of Export Result Using eSATA HDD
7.1.2 Backing up by Event Search
Purpose:
Back up event-related recording files using USB devices, such as USB flash drives, USB HDDs, and USB
writer.
Steps:
1. Enter Export interface.
Menu>Export>Event
2. Search for events.
1) Select the type of event from the dropdown list of Event Type; there are Alarm Input and Motion
selectable.
 Here we take the backup by motion detection as the example.
 Backup by alarm input is supported by DS-7300 and DS-8100 series DVR.
2) Check the checkbox of cameras and set the search time.
3) Click Search button to enter the Search Result interface.
Figure 7. 10 Event Search for Backup
3. Select record files to export.
1) Select an alarm input in the list and click Quick Export button to enter Export interface.
2) Clicking Details button will take you to the interface with detailed information of all channels
triggered by the event.

HIKVISION DS-7104HGHI-SH Specifications

General

Voltage	12 V
Certification	CE
Product color	White
LED indicators	Yes
Channels quantity	4 channels
Maximum frame rate	30 fps
Audio output channels	2.0 channels
Audio formats supported	G.711
Network connection type	RJ-45
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264
Playback resolutions supported	1920 x 1080, 1280 x 1024, 1280 x 720, 1024 x 768
Video in	BNC
Video out	HDMI, VGA
Audio input	1x RCA
BNC input ports	4
USB 2.0 ports quantity	2
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP, HTTPS
HDD interface	Serial ATA
Maximum HDD capacity	4000 GB
Power requirements	DC
Power consumption (typical)	15 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Weight	800 g
Dimensions (WxDxH)	200 x 200 x 45 mm
