HIKVISION DS-7104HWI-SL User Manual

User Manual of Digital Video Recorder
90
Figure 7. 10 Event Search for Backup
5. Click Search button to enter the Search Result interface.
Figure 7. 11 Result of Event Search
6. Select record files to export.
You can enter the Export interface by the following two ways:
 Select motion detection event (s) from the list and click Quick Export button to enter the Export
interface, as shown in Figure 7.15.
 (1) Click the Details button to enter the interface with detailed information of the record file, e.g.,
start time, end time, file size, etc. The size of the currently selected files is displayed in the
lower-left corner of the window.
(2) Select record file (s) from the list and click Export button to enter the Export interface, as shown
in Figure 7.15.

HIKVISION DS-7104HWI-SL Specifications

General

Product color	White
Rack capacity	1U
Maximum frame rate	30 fps
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264
Analog signal format system	NTSC, PAL
Playback resolutions supported	1920x1080, 1280x1024, 1280x720, 1024x768, 704x576, 704x480
BNC input ports	8
Video input channels	4 channels
USB 2.0 ports quantity	2
VGA (D-Sub) output ports	1
Ethernet LAN	Yes
Ethernet interface type	Gigabit Ethernet
HDD interface	Serial ATA
Maximum HDD capacity	4000 GB
DC voltage	12 V
Power consumption (typical)	6 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	200 mm
Height	45 mm
Weight	800 g
