HIKVISION DS-7600NI-E1/A - Front View

All-in-One Network Video Recorder Quick Start Guide
11
Front View
No.
Icon
Description
1
Press it to switch input source.
In main menu interface, press it to select and enter a sub-menu.
In sub-menu interface, press it to exit the sub-menu.
2
In main menu interface, press it to positioning the cursor to the next item
In sub-menu interface, press it to increase the value of a certain item.
3
In main menu interface, press it to positioning the cursor to the upper item
In sub-menu interface, press it to decrease the value of a certain item.
4
Press it to enter main menu.
In main menu interface, press it exit main menu
In sub-menu interface, press it to positioning the cursor to the next item.
5
Turn on/off the LCD displayer.
6
Universal Serial Bus (USB) interface for external USB device.
7
LCD power indicator and IR (Infrared Radiation) receiver.
