HIKVISION DS-K1T6QT-F43 Series

Group No. Funcon Color Name Descripon
C2 White W1 Wiegand
Wiring 1
C3 Black GND Ground
Group D D1 Door Lock White/Purple NC Lock Wiring
(NC)
D2 White/Yellow COM Common
D3 White/Red NO Lock Wiring
(NO)
D4 Yellow/Green SENSOR Door Contact
D5 Black GND Ground
D6 Yellow/Grey BUTTON Exit Door
Wiring
4.2 Wire Normal Device
You can connect the terminal with normal peripherals.
DS-K1T6QT-F43 Series Face Recognion Terminal User Manual
10
