HIKVISION DS-K1T6QT-F43 Series - Wiring Diagram of Door Locked When Powering off

Figure 4-6 Wiring Secure Door Control Unit
4.4.2 Wiring Diagram of Door Locked When Powering
O
Lock Type: Cathode Lock, Electric Lock, and Electric Bolt (NC)
Security Type: Door Locked When Powering
O
Scenario: Installed in Entrance/Exit with Fire Linkage
DS-K1T6QT-F43 Series Face Recognion Terminal User Manual
17
