HIKVISION DS-KD8003-IME1 - Nametag Module

Video Intercom Module Door Station·User Manual
2.2 Nametag Module
Figure 2-2 Nametag Module Appearance
Table 2-2 Appearance Description
No.
Description
1
Call Button
2
Nametag
3
Module-connecting Interface(output)
4
Module-connecting Interface(input)
5
Debug Port
Nametag area supports insert customized name card.
The suggested card size is: 58 (L) x 11.7(W) mm.
