HIKVISION DS-KD8003-IME1 User Manual

Video Intercom Module Door Station·User Manual
5 Device Configuration
You need to activate device and configure corresponding parameters via iVMS-4200
before use.
5.1 Activate Device
You cannot use the door station until you activate it.
You can configure and operate the video intercom devices via iVMS-4200.
Default parameters of door station are as follows:
 Default IP Address: 192.0.0.65.
 Default Port No.: 8000.
 Default User Name: admin.
Steps:
1. Run iVMS-4200, enter Device Management, check the Online Device area.
2. Select an inactivated device and click the Activate button.
3. Create a password, and confirm the password.

HIKVISION DS-KD8003-IME1 Specifications

General

Product color	Black
International Protection (IP) code	IP65
Color	Yes
Relay inputs	2
Video codecs	H.264
Number of buttons	1 buttons
Connectivity technology	Wired
Maximum number of cameras supported	-
Operating system installed	Linux
Megapixel	2 MP
Supported video modes	720p, 1080p
Viewing angle, vertical	96 °
Maximum video resolution	1920 x 1080 pixels
Viewing angle, horizontal	180 °
LED type	IR
Display diagonal	- \
Indoor unit included	No
Voice codecs	G.711u
Networking standards	IEEE 802.3af
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, RTSP
Operating temperature (T-T)	-40 - 60 °C
Operating relative humidity (H-H)	10 - 95 %
Outdoor unit power type	DC
Power consumption (typical)	10 W

Weight and Dimensions

Depth	98 mm
Width	99.8 mm
Height	43.9 mm
