HIKVISION DS-KH6320-WTDE1 User Manual

Chapter 5 Installaon
5.1 Install Indoor Staon
5.1.1 Wall Mounng with Juncon Box
Before You Start
Note
●
Make sure the device in the package is in good condion and all the assembly parts are included.
●
The power supply the indoor staon supports is 12 VDC. Please make sure your power supply
matches your indoor staon.
●
Make sure all the related equipment is
power-o during the installaon.
●
Check the product
specicaon for the installaon environment.
The dimension of juncon box should be 75 mm (width) × 75 mm (length) × 50 mm (depth). The
dimension of wall
mounng plate is shown.
Figure 5-1 Wall Mounng Plate
Steps
1.
Chisel a hole in the wall. The size of the hole should be 76 mm (width) × 76 mm (length) × 50
mm (depth).
2.
Insert the
juncon box to the hole chiseled on the wall.
3.
Fix the wall mounng plate to the juncon box with 2 screws.
4.
Hook the indoor
staon to the wall mounng plate ghtly by inserng the plate hooks into the
slots on the rear panel of the indoor staon, during which the lock catch will be locked
automacally.
Video Intercom Kit User Manual
11
