Figure 5-2 Wall Mounng with Juncon Box
5.1.2
Mounng Indoor Staon without Juncon Box
Before You Start
Note
●
Make sure the device in the package is in good condion and all the assembly parts are included.
●
The power supply the indoor staon supports is 12 VDC. Please make sure your power supply
matches your indoor staon.
●
Make sure all the related equipment is
power-o during the installaon.
●
Check the product
specicaon for the installaon environment.
Steps
1.
Insert 2 expension tubes into the wall.
2.
Fix the wall
mounng plate to the juncon box with 2 screws.
3.
Hook the indoor staon to the wall mounng plate ghtly by inserng the plate hooks into the
slots on the rear panel of the indoor
staon, during which the lock catch will be locked
automacally.
