HIKVISION DS-KH6320-WTE1 Configuration Guide

3.3.2 Set Linked Device IP
Linked network parameters refers to the network parameters of devices (like door staon,
doorphone, main staon, center, etc.), to which the indoor staon is linked. Linked devices for the
indoor staon refers to door staon, center, main staon, and doorphone.
With the private SIP protocol, intercom can be realized only when all these devices are in the same
network segment with the indoor
staon.
With the standard SIP protocol, intercom can be realized when all these devices support the
standard SIP protocol.
Steps
Note
●
The doorphone does not support adding with the standard SIP protocol.
●
Here take main door staon network sengs as example.
1.
Tap Sengs → → Conguraon → to enter the device management page.
Note
Default admin password is the acvaon password.
2.
Tap Main Door Staon to pop up the device informaon dialog.
Figure 3-19 Device Informaon
Set the parameters of the linked door
staon. Tap to set parameters of the door staon.
Network Indoor Staon Conguraon Guide
17

HIKVISION DS-KH6320-WTE1 Specifications

General

Display Size	7 inch
Resolution	1024 × 600
Network Protocols	TCP/IP, SIP, RTSP
Audio Input	Built-in omnidirectional microphone
Audio Output	Built-in loudspeaker
Power Consumption	≤ 6 W
Operation Method	Touchscreen
Audio Compression Standard	G.711 U
Audio Compression Rate	64 Kbps
Wi-Fi Standard	IEEE802.11 b/g/n
Wi-Fi Frequency Range	2.4 GHz
RS-485	1
Working Temperature	-10 °C to 55 °C (14 °F to 131 °F)
Audio	Two-way audio
Power Supply	12 VDC, PoE (IEEE802.3af)
Installation	Wall-mounted
Display Type	TFT LCD
Network Interface	10/100 Mbps Ethernet
Alarm Output	1 channel
TF Card	up to 32 GB
Working Humidity	10% to 90%
