HIKVISION DS-KH6320-WTE1 Configuration Guide

Appendix A. Relevant Instrucons for External
Power Supply and Wiring of 2-wire Video Intercom
Products (2020-1-20)
Power Descripon
2-Wire Distributor
DS-KAD706 CH6 CH1 to CH5
16 W 6 W
DS-KAD704 CH4 CH1 to CH3
16 W 6 W
Modular Door Staon
The main module & the sub-module maximum power consumpon.
Model
Stable Power Consumpon
DS-KD8003-IME2 4 W
DS-KD-KK 0.8 W
DS-KD-KP 1 W
DS-KD-DIS 2.5 W
DS-KD-E 0.8 W
DS-KD-M 0.8 W
DS-KD-INFO 1.5 W
Indoor Staon
Model
Stable Power Consumpon
DS-KH6320-WTE2 6 W
Example of the Calculaon Model of the Modular Door Staon Sub-Module
The sum of the power consumpon of each module must be less than the total power
consumpon of the power supply.
Network Indoor Staon Conguraon Guide
69

HIKVISION DS-KH6320-WTE1 Specifications

General

Display Size	7 inch
Resolution	1024 × 600
Network Protocols	TCP/IP, SIP, RTSP
Audio Input	Built-in omnidirectional microphone
Audio Output	Built-in loudspeaker
Power Consumption	≤ 6 W
Operation Method	Touchscreen
Audio Compression Standard	G.711 U
Audio Compression Rate	64 Kbps
Wi-Fi Standard	IEEE802.11 b/g/n
Wi-Fi Frequency Range	2.4 GHz
RS-485	1
Working Temperature	-10 °C to 55 °C (14 °F to 131 °F)
Audio	Two-way audio
Power Supply	12 VDC, PoE (IEEE802.3af)
Installation	Wall-mounted
Display Type	TFT LCD
Network Interface	10/100 Mbps Ethernet
Alarm Output	1 channel
TF Card	up to 32 GB
Working Humidity	10% to 90%
