HIKVISION DS-MH6171I-A

Network Portable IR Speed Dome Quick Start Guide
16
Figure 2-18 Install Speed Dome
2.3.4 Pendant Mounting
Steps:
1. Punch a hole on the wall according to the size of the pendant mount, and install
the pendant mount to the wall with 4 M6 screws.
Pendant
Mount
Figure 2-19 Install Pendant Mount
2. Loosen the 3 screws on the pendant mount, insert the adapter mount, and fasten
the screws with hexagonal screwdriver.
