HIKVISION iDS-9632NXI-I8/16S User Manual

Network Video Recorder User Manual
110
The captured pictures stored in the HDDs of the device can be searched and viewed.
Step 1 Enter Playback interface.
Step 2 Select Picture from the drop-down list in the upper-left corner of the page to enter the
Picture Playback interface.
Step 3 Check checkbox to select the channel(s) and specify the start time and end time for
search.
Step 4 Click Search to enter Search Result interface.
Up to 4000 pictures can be displayed each time.
Step 5 Choose a picture you want to view and click button.
You can click Back to return to the search interface.
Figure 7-20 Result of Picture Playback
Step 6 The toolbar in the bottom part of Playback interface can be used to control playing process.
Figure 7-21 Picture Playback Toolbar

HIKVISION iDS-9632NXI-I8/16S Specifications

General

Input bandwidth	256 Mbit/s
Output bandwidth	200 Mbit/s
Maximum frame rate	30 fps
Maximum resolution	3840 x 2160 pixels
Alarm input channels	16
Video input channels	16 channels
Alarm output channels	4
Supported resolutions	3840x2160, 1920x1080, 1280x1024, 1280x720, 2560x1440, 1600x1200, 1024x768
Video formats supported	H.264, H.264+, H.265, H.265+, MPEG4
Wi-Fi	No
RAID levels	0, 1, 5, 6, 10
HDD capacity	0 GB
RAID support	Yes
HDD interface	Serial ATA
Maximum storage capacity	80 TB
Number of HDDs installed	0
Number of HDDs supported	8
RS-485 ports	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
Product color	Black
Rack capacity	2U
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	200 W
Power consumption (typical)	70 W
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	470 mm
Width	445 mm
Height	90 mm
Weight	10000 g
