Network Video Recorder User Manual
19
number keys, press Enter to pair unit with the NVR
Disable IR Remote: Press DEV button to clear Device ID#; unit will
no longer be paired with the NVR
3
Switch to the corresponding channel in Live View or PTZ Control
mode
Input numbers in Edit mode
4
Delete characters before cursor
Check the checkbox and select the ON/OFF switch
5
Adjust focus in the PTZ Control menu
Switch on-screen keyboards (upper and lower case alphabet,
symbols, and numerals)
6
Enter Manual Record setting menu
Call a PTZ preset by using the numeric buttons in PTZ control
settings
Turn audio on/off in Playback mode
7
Go to Playback mode
Auto scan in the PTZ Control menu
8
Reserved
9
Switches between main and spot output
Zooms out the image in PTZ control mode
10
Return to Main menu (after successful login)
N/A
Show/hide full screen in Playback mode
12
Navigate between fields and menu items
Use Up/Down buttons to speed up/slow down recorded video,
and Left/Right buttons to advance/rewind 30 secs in Playback
mode
Cycle through channels in Live View mode
Control PTZ camera movement in PTZ control mode
Confirm selection in any menu mode
Checks checkbox
