Need help?Do you have a question about the HIKVISION iDS-TCM203-A and is the answer not in the manual?
General| Form factor | Bullet |
|---|---|
| Mounting type | Ceiling/wall |
| Product color | Gray |
| Protection features | Water resistant |
| International Protection (IP) code | IP66 |
| Type | IP security camera |
| Certification | CE, FCC |
| Placement supported | Outdoor |
| Connectivity technology | Wired |
| Maximum operating distance | 50 m |
| Number of lenses | 1 |
| Focal length range | 8 - 32 mm |
| Maximum aperture number | 1.4 |
| Video streaming | Yes |
| Total megapixels | 2 MP |
| Maximum resolution | 1920 x 1080 pixels |
| Video compression formats | H.264, H.265, M-JPEG |
| Wi-Fi | No |
| Ethernet interface type | Gigabit Ethernet |
| Supported network protocols | TCP/IP, HTTP, HTTPS, FTP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, IPv6, UDP |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 128 GB |
| RS-485 ports | 2 |
| Sensor type | CMOS |
| Optical sensor size | 1/1.8 \ |
| LED type | IR |
| Infra-red wavelength | 850 nm |
| Number of illumination LEDs | 3 |
| Minimum illumination | - lx |
| Field of view (FOV) angle | 42.5 ° |
| Audio input channels | 2 channels |
| Sustainability certificates | RoHS |
| Operating temperature (T-T) | -30 - 70 °C |
| Operating relative humidity (H-H) | 5 - 95 % |
| DC output voltage | 24 |
| Power source type | DC |
| Power consumption (max) | 15 W |
Weight and Dimensions| Depth | 428.5 mm |
|---|---|
| Width | 120 mm |
| Height | 132.8 mm |
| Weight | 3120 g |
