Network Traffic Camera • User Manual
65
− Analysis Rule: You can select Analysis rule as By Direction or By Lane, and draw
corresponding trigger line.
− Offset for Second Capture: It refers to the offset pixel of the second captured picture of
the vehicle running the red light to the stop line. The value ranges from 0
to 300.
− Offset for Third Capture: It refers to the min. offset pixel of the third captured picture of
the vehicle running the red light to the second captured picture. It is
recommended to remain the default value.
Step 5 (Optional) If you check Vehicle on Non-Motor Vehicle Lane, set the time threshold for capture.
Step 6 (Optional)Check Not Yield to Pedestrian, to detect the vehicle that not yields to pedestrian.
Not Yield to Pedestrian function may vary from different models, please refer to actual product.
11.2.2 Configure Lane Parameters and Trigger Rules
Figure 11-5 Lane Parameters and Trigger Rules Configuration
Step 2 Select a lane to configure.
Step 3 Select Direction.
Step 4 Enter Linked Lane No.
Step 5 Select Lane Type.
If you select Opposite Lane, the lane direction will be opposite.
Step 6 Select the driving Direction.
Step 7 Draw LPR area.
