4.1 Sleep Deck
Chapter 4: Removal, Replacement, and Adjustment Procedures
CareAssist® and CareAssist® ES Bed Service Manual (MAN330 REV 4) Page 4 - 5
4
d. Remove the screw (E) securing the CPR handle (F) to the CPR mount
bracket (I).
e. Remove the CPR handle (F) from the CPR cable (G).
f. Loosen, do not remove, the jam nut (H) securing the CPR cable (G) to
the CPR mount bracket (I).
g. Repeat step d through step f for the other side.
h. Remove the E-ring (L) from one side of the lower hinge point (M).
i. Remove the plastic washer (N) from the lower hinge point (M).
j. Repeat step h and step i for the other side.
k. Move the head section to one side to disengage the hinge bracket (O)
from the hinge point (M).
l. Move the head section to the other side to disengage the hinge bracket
(O) from the hinge point (M).
m. Slide the head section (D) toward the head end of the bed to disengage
it from the head section frame.
n. Remove the head section (D) from the bed.
Replacement
1. Do the removal procedure in reverse order.
NOTE:
The seat section can only be installed when the head section is in the full up
position.
2. Make sure the CPR cable is adjusted correctly (refer to procedure 4.6)
3. To make sure the CareAssist® Bed operates correctly, do the “Function
Checks” on page 2-5.

Hill-Rom CareAssist P1170 Specifications

General

Model	CareAssist P1170
Type	Hospital Bed
Weight Capacity	500 lbs (227 kg)
Trendelenburg Position	Yes
Reverse Trendelenburg Position	Yes
Battery Backup	Yes
Frame Material	Steel
Knee Gatch	Yes
Head Section	Adjustable
Foot Section	Adjustable
CPR Release	Yes
Overall Width	39 in
Height Range	15 in to 30 in
Side Rails	Yes
Power Source	Electric
Mattress Type	Foam or Air
Patient Controls	Yes
Wheels	Locking Casters
Warranty	Varies
Overall Length	88 inches (223.5 cm)
