Specifications
Chapter 1: Introduction
Hill-Rom® Basic Care™ Bed, Hill-Rom® 305 Manual Bed, Page 1 - 3
Hill-Rom® 405 Electric Bed Service Manual (MAN336 REV 2)
1
Specifications
Physical Description
Table 1-1. Physical Description
Feature Dimension
Head section slope (maximum) 72.5° ±1°
Knee section slope (maximum) 25° ±1°
Sleep deck height range 18.3" to 30.1" ± 1"
(46.5 cm to 76.5 cm ± 2.5 cm)
Trendelenburg position (maximum) 12° (+2°, -0°)
Reverse Trendelenburg position
(maximum)
12° (+2°, -0°)
Bed lift capacity (maximum safe working
load)
450 lb (204 kg)
Foot section lift capacity (maximum) 200 lb (91 kg)
Head section lift capacity (maximum) 200 lb (91 kg)
Maximum height of seat section (in Tren-
delenburg position)
23.5" (59.7 cm)
Siderail opening size 3.875" (9.843 cm)
Distance between siderails 11.375" (28.893 cm)
Length—with standard sleep deck 89" to 91"
(226 cm to 231 cm)
Length—with short sleep deck 86" to 88" (218 cm to 224 cm)
Sleep deck length—standard model 79" to 81" (201 cm to 206 cm)
Sleep deck length—short model 76" to 78" (193 cm to 198 cm)
Maximum width—with siderails raised 43.7" ± 0.8" (110.9 cm ± 2.0 cm)
Minimum width—with siderail stored 36.6" ± 0.8" (93.0 cm ± 2.0 cm)
Sleep deck width 36.25" ± 0.5 (92.08 cm ± 1.3 cm)
Maximum headboard height 44" (112 cm)
Minimum underbed clearance 5.5" (13.9 cm)
Wheel base 61" (155 cm) Model A bed
58.75" (149 cm) Model B (4-corner brake and
steer)
61.5" (156 cm) Model B (individual casters)
