4.12 Manual Crank Handle Assembly
Chapter 4: Removal, Replacement, and Adjustment Procedures
4
Hill-Rom® Basic Care™ Bed, Hill-Rom® 305 Manual Bed, Page 4 - 27
Hill-Rom® 405 Electric Bed Service Manual (MAN336 REV 2)
4.12 Manual Crank Handle Assembly
Tools required: Small screwdriver
Straps
Removal
1. Raise the knee section and head section to their highest positions.
2. Lift the foot section of the sleep surface, and fold it back toward the head
section.
NOTE:
If either of these sections cannot be raised, this procedure can be done from
underneath the foot end.
WARNING:
Attach the foot section to the head section. Failure to do so could cause
injury.
3. Use straps to attach the foot section to the head section.
4. Remove the footboard (A) from the bed frame (B) (see figure 4-12 on page
4-28).
5. Remove the plastic housing (C) from the crank handle assembly (D).
6. Lift the spring assembly (E) from the groove in the crank handle assembly
(D), and push the spring assembly (E) up the shaft of the crank handle
assembly (D).
7. Pull the crank handle assembly (D) out of the crank rod (F).
