4.15 CPR Handle Assembly
Chapter 4: Removal, Replacement, and Adjustment Procedures
4
Hill-Rom® Basic Care™ Bed, Hill-Rom® 305 Manual Bed, Page 4 - 35
Hill-Rom® 405 Electric Bed Service Manual (MAN336 REV 2)
4.15 CPR Handle Assembly
Tools required: Phillips head screwdriver
8 mm hex wrench
Needle nose pliers
Removal
1. Raise the head section to the highest position.
2. Adjust the bed to a comfortable height in which to work.
Disconnect the bed from its power source. Failure to do so could cause
injury or equipment damage.
3. Disconnect the bed from its power source.
4. Disconnect the battery cable from the control board (refer to procedure 4.7
on page 4-16).
5. Remove the two screws (A) and two bushings (B) that attach the CPR
handle assembly (C) to the bed frame (D) (see figure 4-15 on page 4-36).
6. Remove the spring (E) from the CPR handle assembly (C).
7. Loosen the screw (F) that attaches the CPR wire (G) to the bracket (H).
8. Remove the CPR wire (G) from the bracket (H).
9. Remove the CPR handle assembly (C) from the bed frame (D).
