Base Frame—Model B
Chapter 5: Parts List
5
Hill-Rom® Basic Care™ Bed, Hill-Rom® 305 Manual Bed, Page 5 - 27
Hill-Rom® 405 Electric Bed Service Manual (MAN336 REV 2)
Table 5-9. Base Frame—Model B
Item Number Part Number Quantity Description
1 151414 4 Caster hole covers (includes frame covers)
2 151408 4 Rocker arm assembly
3 151409 2 Brake/steer link, head end
4 151411 2 Brake/steer pedal, right-hand
5 151413 2 Brake/steer pedal, left-hand
6 151412 1 Pedal pad set, brake/steer
7 151410 2 Hex rod, brake/steer
8 131433
131430
131432
131429
131434
1
1
2
3
1
Brake/steer caster
Swivel caster
Brake caster
Individual brake caster
Individual brake/steer caster
