4.2 Control Panel, Foot End
Chapter 4: Removal, Replacement, and Adjustment Procedures
Page 4 - 6 Hill-Rom® Basic Care™ Bed, Hill-Rom® 305 Manual Bed,
Hill-Rom® 405 Electric Bed Service Manual (MAN336 REV 2)
Use caution when you cut the wire ties. Failure to do so could cause
cable damage.
3. Carefully cut all of the wires ties on the two cables (C) from the foot end
control panel (A) to the bed frame (D).
4. Disconnect the two cables (C) from the control box assembly (B).
5. Remove the footboard (E) from the bed frame (D).
6. Remove the two screws (F) that attach the foot end control panel (A) to the
bed frame (D).
7. Remove the foot end control panel (A) from the bed frame (D).
Replacement
1. Do the removal procedure in the reverse order.
2. Do the “Function Checks” on page 2-2.
