4.7 Battery Backup
Chapter 4: Removal, Replacement, and Adjustment Procedures
4
Hill-Rom® Basic Care™ Bed, Hill-Rom® 305 Manual Bed, Page 4 - 17
Hill-Rom® 405 Electric Bed Service Manual (MAN336 REV 2)
5. Make a note of the position of the two batteries (D).
6. Disconnect the battery cable (E) from the control board (F).
7. Disconnect the battery cable (E) and the fuse assembly (G) from the two
batteries (D).
Dispose of batteries in accordance with your local regulations. Failure
to dispose of batteries correctly may damage the environment.
8. Dispose of the two batteries (D) in accordance with your local regulations.
Replacement
1. Do the removal procedure in the reverse order.
2. Do the “Function Checks” on page 2-2.
