LTC Electric Drive Bed Specifications
Chapter 1: Introduction
Resident
TM
LTC Bed Service Manual (man136rc) Page 1 - 21
1
Resident
TM
LTC Electric Drive Bed Specifications
Physical Description
See table 1-3 on page 1-21 for Resident
TM
LTC electric drive bed specifications.
Table 1-3. Resident
TM
LTC Electric Drive Bed Specifications
NOTE:
The head section, knee section, hilow, and automatic contour functions may be
electrically operated to achieve the desired bed position.
WARNING:
Electric or manual drive bed mechanisms can cause serious injury if
operated improperly. Operate the bed only when persons are clear of
the mechanisms.
Head Section Inclination
The head section of the bed may be separately adjusted to obtain the desired
degree of incline up to its limit of approximately 65
o
(± 2
o
). Control of this
function is via the handset control (see “Handset Control” on page 1-25). The
Feature Dimension
Overall length in high position 95 1/4" (241.9 cm)
Overall length in low position 91 1/2" (232.4 cm)
Overall width (siderails up) 42" (106.7 cm)
Overall width (siderails stored) 36" (91.4 cm)
Sleep surface frame height (low position) 13.9" (35.3 cm)
Sleep surface frame height (high position) 29.9" (75.9 cm)
Minimum under bed clearance 5" (12.7 cm)
Maximum head incline elevation 60
o
Maximum knee incline elevation 45
o
Siderail height above sleep surface frame 12 1/2" (31.8 cm)
Bed mass (weight) 275 lb (124.7 kg)
Maximum safe working load— One 400 lb
(181.4 kg) resident plus accessories
480 lb (217.7 kg)
