Chapter 1 Introduction | Hillstone
Hillstone SG-6000 E-Series Hardware Reference Guide
Relative Humidity
10%-95% (non-condensing)
Note: DDR SDRAM is the random access memory to store the communication
data for the CPU. Flash Memory is used for storing the operating system
firmware, configuration and application files.
Ports
This section introduces attributes of interfaces (ports) on the Hillstone devices,
including console port, auxiliary port, USB port, gigabit copper port, SFP port，
QSFP+ ports and XFP port.
Console Port
Hillstone device provides an RS-232C asynchronous serial console port for you to
configure the device. Attributes for the console (CON) port are shown in the
following table.
Table 1-21: Console Port Attributes
Attribute
Description
Connector
RJ-45
Port Standard
RS-232C
Baud Rate
9600/19200/38400/57600/115200 bit/s
Services
Connect the CON port to the serial port of a PC and run a
terminal emulation program on the PC to configure the
device.
Transmission
Medium
console cable
Auxiliary Port
Hillstone device provides an RS-232C asynchronous serial auxiliary (AUX) port.
Attributes for the auxiliary port are shown in the following table.
Table 1-22: Auxiliary Port Attributes
Attribute
Description
Connector
RJ-45
Port Standard
RS-232C
Baud Rate
9600/19200/38400/57600/115200 bit/s
Services
Aux port is used for debugging.
Transmission
Medium
console cable
