*2232121*
2232121 English 25
Fastening to concrete or steel
Description Concrete Steel
minimum distance from the edge of the base material to the
fastener
≥ 70 mm ≥ 15 mm
minimum center-to-center distance between fasteners ≥ 80 mm ≥ 20 mm
minimum base-material thickness ≥ 100 mm Follow the instruc-
tions in the operat-
ing instructions of
the fastener!
3.9 Information about the field of applications
See the Hilti product page for more information about the areas of application.
4 Technical data
WARNING! Always remove the cartridge strip whenever work is interrupted. In this way you avoid
deformation of the plastic strip and the risk of injury due to self-firing in an overheated fastening tool.
When you work at the maximum fastener driving rate, allow the fastening tool to cool down after one hour of
constant work.
DX 6-F8 DX 6-MX DX 6-XIE-L
Weight
3.37 kg 3.63 kg 3.43 kg
Length (fastening tool)
475 mm 485 mm 547 mm
Length (fastener)
13 mm … 72 mm 13 mm … 72 mm 20 mm … 140 mm
Recommended maximum fastening
rate
700 rev/h 700 rev/h 700 rev/h
Required contact pressure
174 N … 200 N 174 N … 200 N 174 N … 200 N
Compression stroke
19 mm 19 mm 19 mm
Ambient temperature (storage and
use)
−15 ℃ … 50 ℃ −15 ℃ … 50 ℃ −15 ℃ … 50 ℃
4.1 Bluetooth
Frequency
2,400 MHz … 2,483.5 MHz
Maximum emitted transmission power
−27.2 dBm
4.2 Noise and vibration information
The sound pressure and vibration values given in these instructions have been measured in accordance with
a standardized test and can be used to compare fastening tools with each other. They can also be used
for a preliminary assessment of exposure. The data given represent the main applications of the fastening
tool. However, if the fastening tool is used for different applications, with different accessories or is poorly
maintained, the data may vary. This can significantly increase exposure over the total working period. An
estimation of the level of exposure should also take into account the periods of time when the fastening
tool is not actually in use. This can significantly reduce exposure over the total working period. Prescribe
additional safety measures to protect the operator from the effects of noise and/or vibration, such as:
Maintenance of the fastening tool and its additional equipment or accessories, keeping the operator's hands
warm, organization of work procedures.
The noise values listed were determined under the following conditions:
Noise information conditions
Cartridge 6.8/11 caliber, black
Energy setting 6
Application Fastening 24 mm wood to concrete (C40) with X-P47 P8
