Page #10 background image
6 English
wood preservative). Only specialists are permitted to handle material
containing asbestos.
Take breaks and do physical exercises to improve the blood circulation
in your fingers. Exposure to vibration during long periods of work can
lead to disorders of the blood vessels and nervous system in the fingers,
hands and wrists.
Electrical safety
Before beginning work, check the working area for concealed electric
cables, gas pipes and water pipes. External metal parts of the power tool
can become live, presenting a risk of electric shock, if you accidentally
damage an electric cable.
Power tool use and care
Immediately switch off the power tool if the accessory tool jams. The
power tool might twist off-line.
Wait until the power tool stops completely before you lay it down.
3 Description
3.1 Product overview 1
@
Dust cap
;
Chuck
=
Accessory tool release
%
Function selector switch
&
Control switch lock
(
Control switch
)
Grip
+
Service indicator
§
Indicator for half power (ATC
version only)
/
Button for half power (ATC
version only)
:
Supply cord
Side handle
3.2 Intended use
The product described is an electrically powered combihammer with pneu-
matic hammering mechanism. It is designed for drilling in concrete, masonry,
wood and metal. The product can also be used for light- to medium-duty
chiseling on masonry and surface finishing work on concrete.
Under certain conditions, the product is also suitable for stirring / mixing.
The tool may be operated only when connected to a power source
providing a voltage and frequency in compliance with the information
given on the type identification plate.
3.3 Active Vibration Reduction (AVR)
The combihammer has an Active Vibration Reduction (AVR) system, which
reduces vibration significantly.
Printed: 02.02.2017 | Doc-Nr: PUB / 5150793 / 000 / 01

Table of Contents

Other manuals for Hilti TE 70-AVR

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Hilti TE 70-AVR and is the answer not in the manual?

Hilti TE 70-AVR Specifications

General IconGeneral
CategoryPower Tool
TypeRotary Hammer
Single Impact Energy11.5 J
Hammer Drilling Diameter Range12 - 40 mm
Drilling Diameter Range (Hammer Drill Bits)12 - 40 mm
Dust Removal Module AvailableYes
Power SourceCorded Electric
Voltage230 V
Drilling ModeHammer drilling, chiseling
Vibration ReductionActive Vibration Reduction (AVR)
Drilling Diameter Range (Hollow Drill Bits)40 - 100 mm
Full Hammering Frequency3510 impacts/minute
Blows Per Minute2760 BPM
Sound Pressure Level91 dB(A)
Tool Chuck TypeSDS-max
Tool HolderSDS-max
Vibration Level9.6 m/s² (Hammer drilling into concrete)
