Hilti TE 70-AVR Original Operating Instructions

8 English
TE 70AVR TE 70-ATC/AVR TE 80-ATC/AVR
Weight
18.3 lb
(8.3 kg)
20.9 lb
(9.5 kg)
21.4 lb
(9.7 kg)
Single impact
energy
11.5 J 11.5 J 11.5 J
Ø hammer drill
bits
1/2 in … 1 3/4 in 1/2 in … 1 3/4 in 1/2 in … 1 3/4 in
Ø hammer drill
bits
12 mm …
45 mm
12 mm …
45 mm
12 mm …
45 mm
Ø drill bits for
wood
13/32 in …
1 1/4 in
13/32 in …
1 1/4 in
13/32 in …
1 1/4 in
Ø drill bits for
wood
10 mm …
32 mm
10 mm …
32 mm
10 mm …
32 mm
Ø drill bits for
metal
0 in … 23/32 in 0 in … 23/32 in 0 in … 23/32 in
Ø drill bits for
metal
0 mm … 20 mm 0 mm … 20 mm 0 mm … 20 mm
5 Operation
Fitting the side handle
CAUTION
Risk of injury! Loss of control over the combihammer.
▶ Check that the side handle is fitted correctly and tightened
securely. Check that the clamping band is engaged in the
groove provided on the tool.
2
Fitting / removing the accessory tool
Note
The use of unsuitable grease may cause damage to the tool.
Use only genuine Hilti grease.
Always check the accessory tool for damage and uneven wear
before each use; replace if necessary.
3
Drilling without hammering
Note
Drilling without hammering is possible when drill bits with a
special connection end are used. Tools of this kind are avail-
able from the Hilti tools range.
For example, when the keyless quick-release chuck is fitted,
smooth-shank drill bits for wood or steel can be used to drill
without hammering.
4
Printed: 02.02.2017 | Doc-Nr: PUB / 5150793 / 000 / 01

Hilti TE 70-AVR Specifications

General

Category	Power Tool
Type	Rotary Hammer
Single Impact Energy	11.5 J
Hammer Drilling Diameter Range	12 - 40 mm
Drilling Diameter Range (Hammer Drill Bits)	12 - 40 mm
Dust Removal Module Available	Yes
Power Source	Corded Electric
Voltage	230 V
Drilling Mode	Hammer drilling, chiseling
Vibration Reduction	Active Vibration Reduction (AVR)
Drilling Diameter Range (Hollow Drill Bits)	40 - 100 mm
Full Hammering Frequency	3510 impacts/minute
Blows Per Minute	2760 BPM
Sound Pressure Level	91 dB(A)
Tool Chuck Type	SDS-max
Tool Holder	SDS-max
Vibration Level	9.6 m/s² (Hammer drilling into concrete)
