Hilti TE 70-AVR Original Operating Instructions

English 9
Mixing
Note
Use the mixing paddle only with the quick-release chuck.
4
TE 70-ATC-AVR
TE 80-ATC-AVR
Setting the power level
Note
Power can be set only when the tool is switched on and ready
for use.
To set the tool to half power, press the "half power" button.
The power indicator lights up to indicate reduced power. Press
the "half power" button again to switch to full power. The
power indicator goes out.
Switching the combihammer off and then on again resets the
tool to full power.
Drilling with hammering action (hammer drilling)
4
Chisel positioning
CAUTION
Risk of injury! Loss of control over the chisel direction.
▶ Do not operate the tool when the selector switch is set to
“Chisel positioning”. Turn the function selector switch until it
engages in the “Chiseling” position.
Note
The chisel can be set to 24 different positions (in 15° incre-
ments). This ensures that flat chisels and shaped chisels can
always be set to the optimum working position.
4
Chiseling
4
Control switch lock
Note
When chiseling, the control switch can be locked in the “on”
position.
6 Care and maintenance
WARNING
Danger of electric shock! Carrying out care and maintenance while the
supply cord is connected to the power outlet presents a risk of serious
injuries including burns.
▶ Always unplug the supply cord before carrying out all care and
maintenance tasks.
Printed: 02.02.2017 | Doc-Nr: PUB / 5150793 / 000 / 01

Hilti TE 70-AVR Specifications

General

Category	Power Tool
Type	Rotary Hammer
Single Impact Energy	11.5 J
Hammer Drilling Diameter Range	12 - 40 mm
Drilling Diameter Range (Hammer Drill Bits)	12 - 40 mm
Dust Removal Module Available	Yes
Power Source	Corded Electric
Voltage	230 V
Drilling Mode	Hammer drilling, chiseling
Vibration Reduction	Active Vibration Reduction (AVR)
Drilling Diameter Range (Hollow Drill Bits)	40 - 100 mm
Full Hammering Frequency	3510 impacts/minute
Blows Per Minute	2760 BPM
Sound Pressure Level	91 dB(A)
Tool Chuck Type	SDS-max
Tool Holder	SDS-max
Vibration Level	9.6 m/s² (Hammer drilling into concrete)
