3.5.7 Automation Network and Fieldbus Interfaces on the X-CB 001 04 Connector
Board
The automation network and the fieldbus interfaces are activated through the integrated
submodule. The submodules determine the interface transmission standard and must be
specified when ordering the module. Only 1 protocol can be run on each interface.
Automation network interface
Ports
2
Designation
AN1, AN2
Transmission standard
Ethernet, 10BASE-T/100BASE-Tx, half and full duplex
IP address
Freely configurable
1)
Subnet mask
Freely configurable
1)
Connection socket
RJ-45
Supported protocols
PROFINET IO Controller V2.4+, see the PROFINET IO manual
(HI 801 559 E).
1
)
Observe the rules for assigning the IP address and the subnet mask, see the PROFINET IO
manual (HI 801 559 E).
Table 4: Data for the Automation Network Interface
i
In accordance with the generally accepted regulation for developing Ethernet networks, no
network loop may occur. Data packets may only reach a controller over a single path.
Fieldbus interface
Number
1
Designation
FB
Transmission standard
Depending on the fieldbus submodule
Connection socket
D-sub connector, 9 poles
Supported protocols
Standard protocols, see communication manual (HI 801 101 E).
Table 5: Data for the Fieldbus Interface
i
Wiring, bus termination:
▪ Observe the corresponding fieldbus standard when connecting the fieldbus interfaces.
▪ Use the bus terminations to terminate the fieldbuses on their physical ends.
