X‑COM 01 E 4 Start-Up
HI 801 566 E Rev. 13.00.00 Page 29 of 46
4.2.2 Mounting and Removing a Module
This chapter describes how to mount and remove the HIMax module. A module can be mounted
and removed while the HIMax system is operating.
NOTICE
Damage to bus and power sockets due to module jamming!
Failure to comply with these instructions can damage the controller.
Always insert the module in the base plate carefully.
Tools and utilities:
▪ Screwdriver, slotted 0.8 x 4.0 mm.
▪ Screwdriver, slotted 1.2 x 8.0 mm.
To insert the modules
1. Open the cover plate on the fan rack:
 Move the locks to the open position.
 Lift the cover plate and insert it into the fan rack.
2. Insert the top of the module into the hook-in rail, see .
3. Swivel the lower edge of the module towards the base plate and apply light pressure to snap
it into place, see .
4. Tighten the screws, see .
5. Pull the cover plate out of the fan rack and close it.
6. Lock the cover plate.
To remove the modules
1. Open the cover plate on the fan rack:
 Move the locks to the open position.
 Lift the cover plate and insert it into the fan rack.
2. Release the screw, see .
3. Swivel the lower edge of the module away from the base plate. Lift and apply light pressure
to remove the module from the hook-in rail, see and .
4. Pull the cover plate out of the fan rack and close it.
5. Lock the cover plate.
