(APPENDIX I) PARAMETERS TABLE | PAGE 61
Parameter PSW Description
Default
value
Range
16 2
Input associated with the AUX1 LED on
the display module.
0
0- Not programmed
1- RC ALARM
2- BP ALARM
3- AT ALARM
4- NA ALARM
5- PRG ALARM 4
6- PRG ALARM 5
7- PE ALARM
8- PRG ALARM 1
9- PRG ALARM 2
10- PRG ALARM 3
11- ENT 1
12- ENT 2
13- ENT 3
14- ENT 4
15- ENT 5
16- ENT P¹
17- ENT T¹
18- ENT TC¹
19-ENT BPA
20-ENT ATA
21-ENT NA
22- Not ENT 1
23- Not ENT 2
24- Not ENT 3
25- Not ENT 4
26- Not ENT 5
27- Not ENT P1
28- Not ENT T1
29- Not ENT TC1
30- Not ENT BPA
31- Not ENT ATA
32- Not ENT NA
17 2
Input associated with the AUX2 LED on
the display module.
0
18 2
Conguration of the preheating and cong-
urable stop outputs.
0
0- PD/PR
1- PE/PR
2- PD/PE
3- PULL/HOLD
4- GAS
19 2 Phase voltage as starting condition 3
0- No consultation
1- Motor started
2- Motor stopped
3- Motor started/stopped
20 2 Alternator voltage as starting condition 1
21 2 PICK-UP input as starting condition. 3
22 2 BPA input as starting condition 2
Tabla 3
Regulations Table
Parameter PSW Description
Default
value
Range
1 2 Fuel transfer pump operating mode. 3
0-Off
1-Manual
2-Automatic
3-Control unit mode/Com-
bined mode
2 2 Default Starting Mode. 1
0-Locked
1-Manual
2-Automatic
3-Test
3 2 Deactivation of D+. 0
0-Alternator
1-Dynamo
4 2 Conguration of the LV relay output. 1
0-Inhibited
1-Fuel transfer pump
2-Heating resistance
3-Thermal protection
5 2 Conguration of the RC input. 1
0-OFF
1- Normally open
2- Normally closed
6 2 Conguration of the BPA input. 1
7 2 Conguration of the ATA input. 1
8 2 Conguration of the NA input. 1
9 2 Conguration of the ENT4 input. 1
10 2 Conguration of the ENT5 input. 1
11 2 Conguration of the PEM input. 2
12 2 Conguration of the ENT1 input. 1
13 2 Conguration of the ENT2 input. 1
14 2 Conguration of the ENT3 input. 1
15 2 Conguration of the SETA1/PC input. 2
¹: Only if the analogue input is congured as a digital input (Regulations table, parameters 35 to 37, va-
lue 1 or 2).
