Himoinsa CEM7 - Page 60

(APPENDIX I) PARAMETERS TABLE | PAGE 60
Parameter PSW Description
Default
value
Range
20 2 Filtering of the ENT5 input. 1.0’’ 0.0’’.. 120.0’’
22 2 Filtering of the ENT1 input. 1.0’’ 0.0’’.. 120.0’’
23 2 Filtering of the ENT2 input. 1.0’’ 0.0’’.. 120.0’’
24 2 Filtering of the ENT3 input. 1.0’’ 0.0’’.. 120.0’’
26 2 Dummy load power detection time. 5 ’’ 1’’..3000’’
27 2 Load starting power detection time. 5 ’’ 1’’..3000’’
28 2 Free. -
29 2 Free. -
30* 2 Gas Ignition activation delay time. 3 ’’ 0’’..100’’
31* 2 Gas valve activation delay time. 1 ’’ 0’’..10’’
32* 2 Gas Ignition deactivation delay time. 1 ’’ 0’’..10’’
33 2 Fumes control activation time. 0 ’’ 0’’..30’’
34 2 IDMT curve time. 36” 0”..3600”
36 2 Stop failure detection time. 90” 1”..3600”
