(APPENDIX I) PARAMETERS TABLE | PAGE 59
Parameter PSW Description
Default
value
Range
42 2 Value of inputs associated to Input Set 1. 0
0..65535
2
43 2 Value of inputs associated to Input Set 2. 0
44 2 Value of inputs associated to Input Set 3. 0
45 2 Value of inputs associated to Input Set 4. 0
INPUT RC BPA ATA NA IN4 IN5 PE IN1 IN2 IN3 SET MAN P T TC
BIT 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14
1
Inputs associa-
0-Input not veried for status detection.
1- Input veried for status detection.
2
nputs associa-
ted to state
Only inputs selected for status verication are evaluated:
0-Input inactive value.
1-Input active value.
NOTE
After modifying parameter 30 the control unit must be reset by disconnecting its
power, to allow the updating of its operating mode.
Tabla 4
Analogue sensors. Related to parameter 29 in the Regulations table
Value
Coolant
temperature
Oil
pressure
Oil
temperature
0 VDO: 323-803-001-008 VDO: 360-081-030-009
PHG7
rev 4.14 and previous:
VDO: 323-803-001-008
rev 4.15 and subse-
quent:
VDO: 323-801-012-00
PHG7J
VDO: 323-801-012-00
1 SCANIA SCANIA
2 Yanmar Yanmar
3 JCB VDO: 360-081-030-009
4 VOLVO VOLVO
5 Programmable 1 Programmable 2
6 Programmable 1 VDO: 360-081-030-009
7 VDO: 323-803-001-008 Programmable 2
8 KUS KUS
Parameter PSW Description
Default
value
Range
24 2 Position of current measured. 0
0- Unit panel
1- Output line
25 3 Management of forced operation. 1
0- Not permitted
1- Starting due to net-
work failure
2- Starting due to forced
26 2
Ratio engine ywheel ring gear speed and
genset voltage frequency.
0
0-50Hz/1500rpm
60Hz/1800rpm
1-50Hz/3000rpm
27 2 Temperature display. 0
0- Celsius
1- Fahrenheit
28 2 Pressure display. 0
0- Bars
29 3 Type of analogue sensors. 0
See table
Analogue sensors
30 2 Selection of control unit type. 0
0- Manual
1- Automatic
31 2
External start conguration
(display: ver. 4.46; measurements ver.
4.00 or higher).
0
0- Alarm delay
1- Immediate start
2- Delay without AL
output activation
3- Immediate start with-
out AL activation
32-33 2 Reserved. - -
34 2 Phase sequence direction. 0
0- Direct
1- Reverse
35 2 Digital input P. 0
0-OFF
1- Normally open
2- Normally closed
36 2 Digital input T. 0
37 2 Digital input TC. 0
38 2 Inputs associated to Input Set 1. 0
0-Non dened set
1..65535- Associated
inputs
39 2 Inputs associated to Input Set 2. 0
40 2 Inputs associated to Input Set 3. 0
41 2 Inputs associated to Input Set 4. 0
