(APPENDIX I) PARAMETERS TABLE | PAGE 58
Parameter PSW Description
Default
value
Range
16 2
Input associated with the AUX1 LED on
the display module.
9
0- Not programmed
1- RC ALARM
2- BP ALARM
3- AT ALARM
4- NA ALARM
5- PRG ALARM 4
6- PRG ALARM 5
7- PE ALARM
8- PRG ALARM 1
9- PRG ALARM 2
10- PRG ALARM 3
11- ENT 1
12- ENT 2
13- ENT 3
14- ENT 4
15- ENT 5
16- ENT P¹
17- ENT T¹
18- ENT TC¹
19-ENT BPA
20-ENT ATA
21-ENT NA
22- Not ENT 1
23- Not ENT 2
24- Not ENT 3
25- Not ENT 4
26- Not ENT 5
27- Not ENT P1
28- Not ENT T1
29- Not ENT TC1
30- Not ENT BPA
31- Not ENT ATA
32- Not ENT NA
17 2
Input associated with the AUX2 LED on
the display module.
10
18 2
Conguration of the preheating and cong-
urable stop outputs.
0
0-PD/PR
1-PE/PR
2-PD/PE
3-PULL/HOLD
4-GAS
19 2 Phase voltage as starting condition. 3
0- No consultation
1- Stabilized
2- Prestart
3- Stabilized and prestart
20 2 Alternator voltage as starting condition. 1
21 2 PICK-UP input as starting condition. 3
22 2 BPA input as starting condition. 2
23 2 Voltage transformer. 0
0- Not installed
1- Transformer 400/600
Tabla 3
Regulations Table
Parameter PSW Description
Default
value
Range
1 2 Fuel transfer pump operating mode. 3
0- Off
1- Manual
2- Automatic
3- Control unit mode/
Combined mode
2 2 Default Starting Mode. 1
0- Locked
1- Manual
2- Automatic
3- Test
3 2 Deactivation of D+. 0
0- Alternator
1- Dynamo
4 2 Conguration of the LV relay output. 1
0- Inhibited
1- Fuel transfer pump
2- Heating resistance
3- Thermal protection
5 2 Conguration of the RC input. 1
0- OFF
1- Normally open
2- Normally closed
6 2 Conguration of the BPA input. 1
7 2 Conguration of the ATA input. 1
8 2 Conguration of the NA input. 1
9 2 Conguration of the ENT4 input. 1
10 2 Conguration of the ENT5 input. 1
11 2 Conguration of the PEM input. 2
12 2 Conguration of the ENT1 input. 1
13 2 Conguration of the ENT2 input. 1
14 2 Conguration of the ENT3 input. 1
15 2 Conguration of the SETA input. 2
¹: Only if the analogue input is congured as a digital input (Regulations table, parameters 35 to
37, value 1 or 2).
