(APPENDIX I) PARAMETERS TABLE | PAGE 63
Parameter PSW Description Default value Range
119 2 Mode alarm extension 3 0 0..2
120 2
Management alarm NFPA
High battery voltage
(from version PHG6 v300)
0 0..4
121 2 Filter alarm NFPA 1 0’ 0”…255”
122 2 Mode alarm NFPA 1 0 0..2
123 2
Management alarm extension 3
Low battery voltage when starting
(from version PHG6 v300)
0 0..4
124 2 Filter alarm NFPA 2 0’ 0”…30”
125 2 Mode alarm NFPA 2 0 0..2
129 2
Management alarm extension 4
Unit power
(from version PHG7 v419)
4 0..4
130 2 Filter alarm extension 4 5’ 0”…255”
131 2 Mode alarm extension 4 0 0..2
132 2
Management alarm probe 1
Temperature probe 1
(from version PHG7 v419)
0 0..4
133 2 Filter alarm probe 1 5’ 0”…255”
134 2 Mode alarm probe 1 0 0..2
135 2
Management alarm probe 2
Temperature probe 2
(from version PHG7 v419)
0 0..4
136 2 Filter alarm probe 2 5’ 0”…255”
137 2 Mode alarm probe 2 0
0..2
138 2
Management alarm probe 3
Temperature probe 3
(from version PHG7 v419)
0 0..4
139 2 Filter alarm probe 3 5’ 0”…255”
140 2 Mode alarm probe 3 0 0..2
141 2
Management alarm probe 4
Temperature probe 4
(from version PHG7 v419)
0 0..4
142 2 Filter alarm probe 4 5’ 0”…255”
143 2 Mode alarm probe 4 0 0..2
144 2
Management alarm J1939
Communication engine
(only expansion PHG7J)
4 0..4
145 2 Filter alarm J1939 1’ 0”…255”
146 2 Mode alarm J1939 0 0..2
Parameter PSW Description Default value Range
87 2 Mode alarm 28 0 0..2
88 2
Management alarm C1
Maximum NETWORK voltage
failure
1
0..1
0. Not checked
1. Checked and if an error
is detected the engine is
started
89 2 Filter alarm C1 5 ’’ 0”…30”
90 2
Management alarm C2
Minimum NETWORK voltage failure
1 0..1
91 2 Filter alarm C2 5 ’’ 0”…30”
92 2
Management alarm C3
Maximum NETWORK frequency
failure
1 0..1
93 2 Filter alarm C3 5 ’’ 0”…30”
94 2
Management alarm C4
Minimum NETWORK frequency
failure
1 0..1
95 2 Filter alarm C4 5 ’’ 0”…30”
96 2
Management alarm C5
Network sequence failure
1 0..1
97 2 Filter alarm C5 5 ’’ 0”…30”
98 2
Management alarm C6
Network signal drop failure
1 0..1
99 2 Filter alarm C6 5 ’’ 0”…30”
100 2
Management alarm C7
CR commutation failure
1
0.Not checked
1.Checked and if an error
is detected the engine is
stopped with cooling
102 2
Management alarm C8
CG commutation failure
1
0.Not checked
1.Checked and if an error
is detected the engine is
stopped with cooling
111 2
Management alarm extension 1
Programmable alarm 4 (from
version PHG6/7 v250)
0 0..4
112 2 Delay alarm extension 1 0’ 0”…30”
113 2 Mode alarm extension 1 0 0..2
114 2
Management alarm extension 2
Programmable alarm 5
(from version PHG6/7 v250)
0 0..4
115 2 Delay alarm extension 2 0’ 0”…255”
116 2
Mode alarm extension 2 0 0..2
117 2
Management alarm extension 3
Auxiliary battery alarm
(from version PHG6/7 v250)
0 0..4
118 2 Filter alarm extension 3 0’ 0”…255”
