(APPENDIX I) PARAMETERS TABLE | PAGE 64
Tabla 8
Alarms Table
Parameter PSW Description Default value Range
1 3
Management alarm 0
High Water Temperature
1
0- Not checked
1- Always checked
2- When starting
3- From start condition
(Stabilised)
4- From nominal condi-
tion (In operation)
2 3 Delay alarm 0 0 ’’ 0”…255”
3 3 Mode alarm 0 1
0- Not for engine
1- For engine
2- For engine with
cooling
4
3
Management alarm 1
Low oil pressure
4 0..4
5 3 Delay alarm 1 15’’ 0”…255”
6 3 Mode alarm 1 1 0..2
10 2
Management alarm 3
Battery Alternator failure
3 0..4
11 2 Filter alarm 3 5 ’’ 0”…255”
12 2 Mode alarm 3 0 0..2
16 3
Management alarm 5
Low Water Level
1 0..4
17 3 Delay alarm 5 5 ’’ 0”…255”
18 3 Mode alarm 5 1 0..2
19 2
Management alarm 6
Fuel Reserve
1 0..4
20 2 Delay alarm 6 5 ’’ 0”…255”
21 2 Mode alarm 6 0 0..2
22 2
Management alarm 7
Overspeeding
4 0..4
23 2 Filter alarm 7 5 ’’ 0”…255”
24 2 Mode alarm 7 1 0..2
25 2
Management alarm 8
Under Speed
4 0..4
26 2 Filter alarm 8 15” 0”…255”
27 2 Mode alarm 8 2 0..2
28 2
Management alarm 9
Overload
4 0..4
29
2 Filter alarm 9 15” 0”…255”
30 2 Mode alarm 9 2 0..2
Parameter PSW Description
Default
value
Range
32 2 Dummy load activation power . 0KW
0: Disabled
1...10000
33 2 Dummy load deactivation power. 0KW
0: Disabled
1...10000
34 2 Starting activation power by load demand. 0KW
0: Disabled
1...10000
35 2 Starting deactivation power by load demand. 0KW
0: Disabled
1...10000
36 2 Maximum battery voltage. 32 8-40
37 2 Minimum battery voltage when starting. 10 8-23
38 2 Percentage of maximum genset power. 90 0-110%
39 2 Maximum temperature of external probe 1. 0 0-250ºC
40 2 Maximum temperature of external probe 2. 0 0-250ºC
41 2 Maximum temperature of external probe 3. 0 0-250ºC
42 2 Maximum temperature of external probe 4. 0 0-250ºC
43 2
Maximum temperature level 2 of external
probe 1.
0 0-250ºC
44 2
Maximum temperature level 2 of external
probe 2.
0 0-250ºC
45 2
Maximum temperature level 2 of external
probe 3.
0 0-250ºC
46 2
Maximum temperature level 2 of external
probe 4.
0 0-250ºC
47 2
Maximum current of neutral
(only CEP7).
0 0..100A
48 2 Cut-off temperature of preheating. 0
0-Cut-off
disabled
1..125ºC
51 2 IDMT curve intensity. 200% 101..200%
52 2 Maximum temperature of external probe 5. 0 0-250°C
53 2 Maximum temperature of external probe 6. 0 0-250°C
54 2 Maximum temperature of external probe 7. 0 0-250°C
55 2 Maximum temperature of external probe 8. 0 0-250°C
56 2
Maximum temperature level 2 of external
probe 5.
0 0-250°C
57 2
Maximum temperature level 2 of external
probe 6.
0 0-250°C
58 2
Maximum temperature level 2 of external
probe 7.
0 0-250°C
59 2
Maximum temperature level 2 of external
probe 8.
0 0-250°C
60 2 Low power threshold. 20 0-100%
61 2 Current asymmetry threshold. 30% 0-100%
