Himoinsa CEM7 - Page 65

(APPENDIX I) PARAMETERS TABLE | PAGE 65
Parameter PSW Description Default value Range
60 2 Mode alarm 19 2 0..2
61 2
Management alarm 20
Minimum Unit Voltage
3 0..4
62 2 Filter alarm 20 8” 0”…255”
63 2 Mode alarm 20 2 0..2
64 2
Management alarm 21
Minimum Unit Frequency
3 0..4
65 2 Filter alarm 21 8” 0”…255”
66 2 Mode alarm 21 2 0..2
70 2
Management alarm 23
Stop failure
1 0..1
71 2 Filter alarm 23 5 ’’ 0”…255”
73 2
Management alarm 24
Low Engine Temperature
0 0..4
74 2 Filter alarm 24 15’’ 0”…255”
75 2 Mode alarm 24 0
0- Not CG limited
1- CG limited
76 2
Management alarm 25
Unit signal failure
3 0..4
77 2 Filter alarm 25 2” 0”…255”
78 2 Mode alarm 25 2 0..2
79 2
Management alarm 26
Programmable alarm 1
0 0..4
80 2 Delay alarm 26 0’ 0”…255”
81 2 Mode alarm 26 0 0..2
82 2
Management alarm 27
Programmable alarm 2
0 0..4
83 2 Delay alarm 27 0’ 0”…255”
84 2 Mode alarm 27 0 0..2
85 2
Management alarm 28
Programmable alarm 3
0 0..4
86 2 Delay alarm 28 0’ 0”…255”
87 2 Mode alarm 28 0 0..2
88...99 2 Switching network alarms -
See switching controller
manual.
100 2
"Management alarm C7
CR switching failure"
1
0- Not veried
1- Veried, if failure
starts engine.
102 2
Management alarm
Genset breaker alarm
0 0..1
104..110 - Switching genset alarm -
See switching controller
manual.
Parameter PSW Description Default value Range
31 2
Management alarm 10
Asymmetry
3 0..4
32 2 Filter alarm 10 8” 0”…255”
33 2 Mode alarm 10 2 0..2
34 2
Management alarm 11
Maximum Unit Voltage
3 0..4
35 2 Filter alarm 11 5 ’’ 0”…255”
36 2 Mode alarm 11 1 0..2
37 2
Management alarm 12
Maximum Unit Frequency
4 0..4
38 2 Filter alarm 12 1 ’’ 0”…255”
39 2 Mode alarm 12 1 0..2
40 2
Management alarm 13
Incorrect Phases Sequence
4 0..4
41 2 Filter alarm 13 8” 0”…255”
42 2 Mode alarm 13 2 0..2
43 2
Management alarm 14
Reverse Power
4 0..4
44 2 Filter alarm 14 15” 0”…255”
45 2 Mode alarm 14 2 0..2
46 2
Management alarm 15
Low battery voltage
1 0..4
47 2 Filter alarm 15 15” 0”…255”
48 2 Mode alarm 15 0 0..2
49 2
Management alarm 16
High Water Temperature (by sensor)
1 0..4
50 2 Filter alarm 16 5 ’’ 0”…255”
51 2 Mode alarm 16 0 0..2
52 2
Management alarm 17
Low oil pressure (by sensor)
3 0..4
53 2 Filter alarm 17 5 ’’ 0”…255”
54 2 Mode alarm 17 0 0..2
55
2
Management alarm 18
Low fuel level (by sensor)
1 0..4
56 2 Filter alarm 18 5 ’’ 0”…255”
57 2 Mode alarm 18 0 0..2
58 2
Management alarm 19
Short Circuit
4 0..4
59 2 Filter alarm 19 __
