(APPENDIX I) PARAMETERS TABLE | PAGE 69
Parameter PSW Description
Default
value
Range
25 2
Input associated to preheating
cut-off
0
See table 11 – Programmable con-
trol unit outputs
26 2 Input associated to AL6 mode 0
27 2 Input associated to AL7 mode 0
28 2 Input associated to AL8 mode 0
29 2 Input associated to AL9 mode 0
30 2 Input associated to AL10 mode 0
31 2 Input associated to AL11 mode 0
32 2 Input associated to AL12 mode 0
33 2 Input associated to AL13 mode 0
34 2 Input associated to AL14 mode 0
35 2 Input associated to AL15 mode 0
36 2 Input associated to AL16 mode 0
37 2 Input associated to AL17 mode 0
38 2 Input associated to AL18 mode 0
39 2 Input associated to AL19 mode 0
40
2
Input associated to AL20 mode
0
41 2 AL output mode 0
See table 10 – Programmable con-
trol unit outputs
42 2 MA output mode 0
43 2 PR output mode 0
44 2 BT output mode 0
45 2 Modo Salida CG 0
46 2
Input associated with forced
catalyst regeneration
0
See table 11 – Programmable con-
trol unit outputs
47 2
Input associated with inhibited
catalyst regeneration
0
48 2
Input associated with interlock
catalyst regeneration
0
Tabla 10
Programmable control unit outputs
Value Function
0 Not programmed
1 RC input
2 BP input
3 AT input
4 NA input
5 ENT4 input
6 ENT5 input
7 PE alarm
8 ENT1 input
9 ENT2 input
10 ENT3 input
11 Heating resistance
12 Block mode
13 Manual mode
14 Auto mode
15 Test mode
16 Alternator alarm
17 Alarm 1
18 Alarm 2
19 Alarm 3
20 Alarm 4
21 Alarm 5
22 Dummy load
23 Thermal protection
24 Load demand
25 HOLD control engine
26 Gas valve (only gas engine)
27 Unit contactor opening
29 Unit contactor status
30 Network contactor status (only automatic control unit)
31 Watchdog
