Himoinsa CEM7 - Page 70

(APPENDIX I) PARAMETERS TABLE | PAGE 70
Value Function
32..95 Unit alarm (see Table of Programmable output genset alarms allocation)
96 Stabilized engine
97 Fumes control
98 Mains present
99..130 Unit alarm (see Table of Programmable output genset alarms allocation)
131 YANMAR oil pump
132 Input Set 1
133 Input Set 2
134 Input Set 3
135 Input Set 4
Tabla 11
Programmable control unit functions
Value Function
0 Not programmed
2 2-BPA
3 3-ATA
4 4-NA
5 5- ENT4
6 6- ENT5
8 8-ENT1
9 9-ENT2
10 10-ENT3
13 13-ENT P
14 14-ENT T
15 15-ENT C
17 Extension ENT 1.1 (CCPT100 or CCIn8 ID 0, input 1) (See Section 5.8)
18 Extension ENT 1.2 (CCPT100 or CCIn8 ID 0, input 2) (See Section 5.8)
19 Extension ENT 1.3 (CCPT100 or CCIn8 ID 0, input 3) (See Section 5.8)
20 Extension ENT 1.4 (CCPT100 or CCIn8 ID 0, input 4) (See Section 5.8)
21 Extension ENT 1.5 (CCIn8 ID 0, input 5) (See Section 5.8)
22 Extension ENT 1.6 (CCIn8 ID 0, input 6) (See Section 5.8)
Value Function
23 Extension ENT 1.7 (CCIn8 ID 0, input 7) (See Section 5.8)
24 Extension ENT 1.8 (CCIn8 ID 0, input 8) (See Section 5.8)
25 Extension ENT 2.1 (CCPT100 or CCIn8 ID 1, input 1) (See Section 5.8)
26 Extension ENT 2.2 (CCPT100 or CCIn8 ID 1, input 2) (See Section 5.8)
27 Extension ENT 2.3 (CCPT100 or CCIn8 ID 1, input 3) (See Section 5.8)
28 Extension ENT 2.4 (CCPT100 or CCIn8 ID 1, input 4) (See Section 5.8)
29 Extension ENT 2.5 (CCIn8 ID 1, input 5) (See Section 5.8)
30 Extension ENT 2.6 (CCIn8 ID 1, input 6) (See Section 5.8)
31 Extension ENT 2.7 (CCIn8 ID 1, input 7) (See Section 5.8)
32 Extension ENT 2.8 (CCIn8 ID 1, input 8) (See Section 5.8)
33 Extension ENT 3.1 (CCPT100 or CCIn8 ID 2, input 1) (See Section 5.8)
34 Extension ENT 3.2 (CCPT100 or CCIn8 ID 2, input 2) (See Section 5.8)
35 Extension ENT 3.3 (CCPT100 or CCIn8 ID 2, input 3) (See Section 5.8)
36 Extension ENT 3.4 (CCPT100 or CCIn8 ID 2, input 4) (See Section 5.8)
37 Extension ENT 3.5 (CCIn8 ID 2, input 5) (See Section 5.8)
38 Extension ENT 3.6 (CCIn8 ID 2, input 6) (See Section 5.8)
39 Extension ENT 3.7 (CCIn8 ID 2, input 7) (See Section 5.8)
40 Extension ENT 3.8 (CCIn8 ID 2, input 8) (See Section 5.8)
41 Extension ENT 4.1 (CCPT100 or CCIn8 ID 3, input 1) (See Section 5.8)
42 Extension ENT 4.2 (CCPT100 or CCIn8 ID 3, input 2) (See Section 5.8)
43 Extension ENT 4.3 (CCPT100 or CCIn8 ID 3, input 3) (See Section 5.8)
44 Extension ENT 4.4 (CCPT100 or CCIn8 ID 3, input 4) (See Section 5.8)
45 Extension ENT 4.5 (CCIn8 ID 3, input 5) (See Section 5.8)
46 Extension ENT 4.6 (CCIn8 ID 3, input 6) (See Section 5.8)
47 Extension ENT 4.7 (CCIn8 ID 3, input 7) (See Section 5.8)
48 Extension ENT 4.8 (CCIn8 ID 3, input 8) (See Section 5.8)
49 Input Set 1 (See Section 4.13)
50 Input Set 2 (See Section 4.13)
51 Input Set 3 (See Section 4.13)
52 Input Set 4 (See Section 4.13)
53 CEC 0.ENT1 (CEC ID 0, input 1) (See Section 5.8)
54 CEC 0.ENT2 (CEC ID 0, input 2) (See Section 5.8)
