(APPENDIX III) DIMENSIONS, WIRING AND MECHANICAL PARTS | PAGE 93
Symbol Parameter Conditions Minimum Typical Maximum Unit
Environmental conditions and protection of the enclosure
To Operating temperature -20 +60 ºC
H
R
Relative humidity No
condensation
80 %
IP Degree of Protection *see note 1 65
NOTE 1
IP 65 on the front of the control unit when installed on the control panel with
the sealing gasket provided.
The equipment has been designed and manufactured according to the require-
ments of the directives and harmonized standards which are applicable for com-
pliance with EC regulations.
DIMENSIONS
Fig.1
PHG7 module dimensions
