(APPENDIX III) DIMENSIONS, WIRING AND MECHANICAL PARTS | PAGE 99
NOTE 1:
IP 65 on the front of the control unit when installed on the control panel with
the sealing gasket provided.
The equipment has been designed and manufactured according to the require-
ments of the directives and harmonized standards which are applicable for com-
pliance with EC regulations.
DIMENSIONS
Fig.5
PHG7J module dimensions.
