Hioki IM3536-01 - Page 53

49
Setting Measurement Conditions (basic settings)
(2) DC measurement
No. 3 parameter
No. 1
parameter
OFF Rdc
OFF ×

Rdc
 
×: Invalid setting (Same operation as AUTO setting),

: Congurable
Measurement signal level (AC)
Sets the measurement signal level to apply to the sample.
The measurement signal level applied to the sample can be set using the following three modes:
(See "About the measurement signal mode" (p. 53).)
Open circuit voltage (V) mode
The value of the open circuit voltage is set.
Constant voltage (CV) mode
The value of the voltage between the terminals of the object under
test is set.
Constant current (CC) mode
The value of the current owing through the object under test is set.
Selecting constant-voltage or constant-current mode will result in longer measurement times (due
to the use of software feedback control).
For some samples, changing the measurement signal level setting will cause measured values to vary.
CAUTION
Do not switch between V, CV and CC while the test sample is still connected to the
measurement terminals because doing so may damage the test sample.
Screen display method (For more information, see p. 24.):
(Measurement screen) SET key>(SET screen) BASIC tab>LEVEL key
3
Performing Measurements in LCR Mode
