24
M3X3SS …………………4
Balance the stabilizer blade and adjust by
winding tape, etc. around the lighter side.
Caution
Attachment of the stabilizer blade
スタビライザーブレード
Stabilizer blade
M3X3SS
A 115mm
B
A = B
Stabilizer blade and stabilizer control
arm must be assembled so that they
parallel to one another.
Caution
○ スタビライザーブレードは左右同じ位置に取り付け
てください。A=B 標準長さ 115mm ± 2mm
Stabilizer plate: Attach the stabilizer bars so that they are
in the same position to the left and right. A=B Standard
length: 115mm +/- 2mm.
