5.1 LIMIT SETTING
The LMI system has been equipped with programmable limits for the crane's operation range.
• Easy programming due to interactive, step-by-step user guidance
• Functions can be used individually or in combinations.
• Exceeding a programmed limit triggers an audible and visual alarm.
• Depending on the crane type not all functions listed below are available.
Overview limits:
Slewing Angle Limitation /
Work Area Definition
(⇒ chapter 5.1.1)
Tip Height Limitation
(⇒ chapter 5.1.2)
Boom Angle Limitation
(⇒ chapter 5.1.3)
Radius Limitation
(⇒ chapter 5.1.4)
