Network load control
36
8.6 VLANs
Basic - L3P
Release 4.0 11/07
Figure 41: Example of a VLAN
Key words often used in association with VLANs are:
 Ingress rule
The ingress rules stipulate how incoming data is to be handled by the
Switch.
MACH 3002
RS2
MICE
