Operation diagnosis
12
9.3
Out-of-band signaling
Basic - L3P
Release
4.0
11/07
9.3.2 Monitoring correct operation via the signal
contact
Configuring the operation monitoring
Displaying the signal contact
The Switch gives you three options for displaying the status of the signal
contact:
X LED display
X display in the Web-based interface
X query in the Command Line Interface.
Select the Diagnostics:Signal Contact dialog.
Select "Monitoring correct operation" in the "Mode signal contact"
frame to use the contact for operation monitoring.
In the "Monitoring correct operation" frame, you select the events
you want to monitor.
To monitor the temperature, you set the temperature thresholds in
the Basics:System dialog at the end of the system data.
enable Switch to the Priviledged EXEC mode.
configure Switch to the Configuration mode.
signal-contact 1 monitor all Includes all the possible events in the operation
monitoring.
signal-contact 1 trap enable Enables a trap to be sent if the status of the oper-
ation monitoring changes.
