Operation diagnosis
Basic - L3P
Release
4.0
11/07
9.3
Out-of-band signaling
11
9.3.1 Controlling the signal contact
With this mode you can remotely control every signal contact individually.
Application options:
X Simulation of an error during SPS error monitoring.
X Remote control of a device via SNMP, such as switching on a camera.
Select the Diagnostics:Signal Contact 1/2) dialog.
In the "Mode Signal contact" frame, you select the "Manual setting"
mode to switch the contact manually.
Select "Opened" in the "Manual setting" frame to open the contact.
Select "Closed" in the "Manual setting" frame to close the contact.
enable Switch to the Priviledged EXEC mode.
configure Switch to the Configuration mode.
signal-contact 1 mode manual Select the manual setting mode for signal contact
1.
signal-contact 1 state open Open signal contact 1.
signal-contact 1 state closed Close signal contact 1.
