Network load control
Basic - L3P
Release 4.0 11/07
8.6 VLANs
39
Note: Save the VLAN configuration to non-volatile memory (see fig.
47).
Note: The 256 available VLANs can use any VLAN ID between 1 and
4042.
Note: In a HIPER-Ring with VLANs, you should only operate devices
with the software that supports this function:
X RS2 xx/xx (from vers. 7.00),
X RS2-16M,
X RS 20, RS 30, RS 40
X MICE (from rel. 3.0) or
X Power MICE
X MS 20, MS 30
X MACH 1000
X MACH 4000
X MACH 3000 (from rel. 3.3)
X OCTOPUS
Note: In the HIPER-Ring configuration, select for the ring ports
X VLAN ID 1 and "Ingress Filtering" in the port table and
X VLAN membership U in the static VLAN table.
