Access to the user interfaces
Basic - L3P
Release
4.0
11/07
1.1
System Monitor
9
Figure 1: Screen display during the boot process
Press the <1> key within one second to start system monitor 1.
Figure 2: System monitor 1 screen display
Select a menu item by entering the number.
To leave a submenu and return to the main menu of system monitor 1,
press the <ESC> key.
< PowerMICE MS4128-5 (Boot) Release: 1.00 Build: 2005-09-17 15:36 >
Press <1> to enter System Monitor 1 ...
1
System Monitor
(Selected OS: L3P-01.0.00-K16 (2005-10-31 19:32))
1 Select Boot Operating System
2 Update Operating System
3 Start Selected Operating System
4 End (reset and reboot)
5 Erase main configuration file
sysMon1>
